The EpeirIO Family

The EpeirIO modules family provides all the features for a variety of intelligent control applications. The different models provide  controllable full bridges (H bridges), SSR or up to sixteen IOs. Use multiple modules together to control many devices.

The EpeirIO modules are fully configurable, with easy-to-use software with multiple toolboxes for module configuration and for data analysis.

Applications

  • Intelligent System Control.

  • Scientific Analysis.

  • LED Lighting Control.

  • DC Relay Control.

  • Industrial Control.

  • DC/DC, AC/DC Controller.

  • and more....

Software Toolbox for EpeirIO Configurations

  • Reliability:  module redundancy.

  • Scalability:  cascading multiple modules together to control larger systems.

  • Intelligent Control Toolbox:  sensorless control, motor control, adaptive control, neural networks, fuzzy control and machine learning.

  • Scope: data acquisition, measurements, real-time analysis,...

  • Sequencer:  event table.

  • Temporal Functions: ramp up, ramp down, delay, hysteresis, etc.

  • Math Functions.

  • Digital Signal Acquisition: digital filter, FFT, …

  • Communication Ports: SPI, RS485, Ethernet, Wi-Fi, USB, powerline, IOT, Raspberry PI connector, BeagleBone connector, etc.

  • Inputs: analog 16bits, analog 24bits, digital, etc.

  • Output: H-bridge (DC), SSR (AC), phase angle control (AC), etc.

  • Output Control: AC motor, DC motor, stepper motor, servo motor, current control (DC and AC), voltage control (DC and AC), DAC, etc.

EpeirIO-2HBDC

In Production

Control

Input

Output

Communication Port

Power Supply

Analog Features

2 x H-bridge 30V, 5A

4 x digital/analog 16bits

-

2 x configurable

10-30V DC

2 x simultaneous sampling channels, 0-5V, 500KHz

EpeirIO-2HBPL

In Production

Control

Input

Output

Communication Port

Power Supply

Analog Features

2 x H-bridge 30V, 5A

4 x digital/analog 16bits

-

1 x configurable, PLC

10-30V DC

2 x simultaneous sampling channels, 0-5V, 500KHz

EpeirIO-2IO16PL

Under Development

Control

Input

Output

Communication Port

Power Supply

Analog Features

-

2 x digital/analog 16bits

-

1 x configurable, PLC

10-30V DC

2 x simultaneous sampling channels, 0-5V, 500KHz

EpeirIO-2SSRAC

Under Development

Control

Input

Output

Communication Port

Power Supply

Analog Features

2 x SSR 15A

4 x digital/analog 16bits

1 x digital/analog 16bits

1 x configurable

80-480V AC, 50/60Hz

2 x simultaneous sampling channels, 0-5V, 500KHz

EpeirIO-8IO24DC

Under Development

Control

Input

Output

Communication Port

Power Supply

Analog Features

-

8 x digital/analog 24bits

8 x digital/analog 24bits

2 x configurable, 1 x Ethernet

10-30V DC

8 x simultaneous sampling channels, 0-5V, 500KHz, 100KSPs, 110dB SNR
